Cáp truyền dữ liệu Elettrotekkabel Flexidrum® TD 210 C TP

0914 237 179

Email: sale11@ltdautomation.com.vn

Lượt xem:
39
Nhà sản xuất:
Elettrotekkabel
Model:
Flexidrum® TD 210 C TP
Giá:
Liên hệ

Tư vấn ngay: 0914 237 179 - sale11@ltdautomation.com.vn

FLEXIBLE AT LOW TEMPERATURES
HIGH ABRASION RESISTANCE
MAT SURFACE OUTER SHEATH
GOOD AGAINST ACIDS, ALKALINES,SOLVENTS,HYDRAULIC LIQUIDS ETC
GOOD EMC RESISTANCE
AWM STYLE 21198 80°C 300 VCSA AWM I/II A/B 80°C 300V FT1 FT2 CE
OR: c us AWM STYLE 20233 80°C 300 V FT2 CE
FOR SPEEDS AND MINIMUM BENDING RADIUS SEE PAGES FROM 1 TO 4 OF CATALOGUE
ROHS AND CE APPROVAL

Thông tin sản phẩm
Bình luận

Technical Data	Specification
Nominal Voltage
- DIN VDE	Uo/U 300/500 V
- UL/CSA	300 V
Test Voltage
- DIN VDE 0472 Part 509	1.5 kV
- Core/Screen	1.2 kV
Temperature Range
- Fixed Laying (DIN VDE)	-50°C to +90°C
- Flexible Installation (DIN VDE)	-40°C to +90°C
- UL/CSA	Up to +80°C
Radiation Resistance	5 x 10⁷ CJ/Kg
Minimum Bending Radius	7.5 x D (continuously flexible)
Max Speed (Main Application)	250 m/min

Part No.	No. of Cores	X Cross Section (n x mm²)	Outer-Ø (ca. mm ± 10%)	Copper Weight (kg/km)	Cable Weight Approx. (kg/km)	AWG No.
36370C64022A26	2 X 2	0.14	5.9	17	28	26
36370C64032A26	3 X 2	0.14	6.2	21	32	26
36370C64042A26	4 X 2	0.14	6.6	24.9	39	26
36370C64052A26	5 X 2	0.14	6.7	28.8	46	26
36370C64062A26	6 X 2	0.14	7.4	34	-	26
36370C64072A26	7 X 2	0.14	7.8	35.9	59	26
36370C64082A26	8 X 2	0.14	8.8	42	-	26
36370C64102A26	10 X 2	0.14	9.3	50	72	24
36370C64142A26	14 X 2	0.14	10	69.8	96	26
36370C64182A26	18 X 2	0.14	10.4	89.6	129	26
36370C64252A26	25 X 2	0.14	11.7	114.3	170	26
36370C64012A24	1 X 2	0.25	4.7	15	-	24
36370C64022A24	2 X 2	0.25	6.3	26	35	24
36370C64032A24	3 X 2	0.25	6.6	32	44	24
36370C64042A24	4 X 2	0.25	7.5	38.5	52	24
36370C64052A24	5 X 2	0.25	8.2	43.5	71	24
36370C64062A24	6 X 2	0.25	8.4	50.6	89	24
36370C64072A24	7 X 2	0.25	8.5	54.1	92	24
36370C64082A24	8 X 2	0.25	10	67.1	-	24
36370C64102A24	10 X 2	0.25	11.7	87	101	24
36370C64142A24	14 X 2	0.25	11.9	110	153	24
36370C64182A24	18 X 2	0.25	12.5	133.4	189	24
36370C64252A24	25 X 2	0.25	15.8	184.8	262	24
36370C64012A22	1 X 2	0.34	4.9	17	-	22
36370C64022A22	2 X 2	0.34	6.7	31	40	22
36370C64032A22	3 X 2	0.34	7.1	38.5	52	22
36370C64042A22	4 X 2	0.34	7.7	50	63	22
36370C64052A22	5 X 2	0.34	8.1	53.1	73	22
36370C64062A22	6 X 2	0.34	9.3	77	-	22
36370C64072A22	7 X 2	0.34	9.8	86	94	22
36370C64082A22	8 X 2	0.34	11.5	96	-	22
36370C64102A22	10 X 2	0.34	12.5	113	121	22
36370C64142A22	14 X 2	0.34	13	138.3	181	22
36370C64182A22	18 X 2	0.34	13.9	169.2	223	22
36370C64252A22	25 X 2	0.34	14.2	247.3	313	22
36370C64012A20	1 X 2	0.5	5.2	28	-	20
36370C64022A20	2 X 2	0.5	7.7	38.5	52	20
36370C64032A20	3 X 2	0.5	7.9	51.2	69	20
36370C64042A20	4 X 2	0.5	8.9	64.2	87	20
36370C64052A20	5 X 2	0.5	9.3	80	115	20
36370C64062A20	6 X 2	0.5	10.9	92.1	147	20
36370C64072A20	7 X 2	0.5	11	108.4	161	20
36370C64082A20	8 X 2	0.5	12.7	118	175	20
36370C64102A20	10 X 2	0.5	14.2	152	192	20
36370C64142A20	14 X 2	0.5	14.4	197	276	20
36370C64182A20	18 X 2	0.5	16.5	257.8	345	20
36370C64252A20	25 X 2	0.5	19.5	336.5	446	20
36370C64022A19	2 X 2	0.75	8.7	50.7	69	19
36370C64032A19	3 X 2	0.75	9.2	67.6	87	19
36370C64042A19	4 X 2	0.75	10.5	99.2	112	19
36370C64052A19	5 X 2	0.75	11.5	118.8	163	19
36370C64062A19	6 X 2	0.75	11.6	134	-	19
36370C64072A19	7 X 2	0.75	12.5	148	212	19
36370C64082A19	8 X 2	0.75	13.9	178.5	258	19
36370C64102A19	10 X 2	0.75	15.3	213	296	19
36370C64122A19	12 X 2	0.75	16.8	263	358	19
36370C64142A19	14 X 2	0.75	18.3	281	390	19
36370C64182A19	18 X 2	0.75	19.5	366.1	482	19
36370C64252A19	25 X 2	0.75	22.5	480.5	620	19
36370C64022A18	2 X 2	1	9.7	68	-	18
36370C64032A18	3 X 2	1	10	88	128	18
36370C64042A18	4 X 2	1	11	107.2	153	18
36370C64052A18	5 X 2	1	11.7	119.4	190	18
36370C64062A18	6 X 2	1	13	153.6	250	18
36370C64082A18	8 X 2	1	15.6	191	370	18
36370C64022A16	2 X 2	1.5	11.8	98	-	16
36370C64042A16	4 X 2	1.5	13.7	163.2	230	16
36370C64062A16	6 X 2	1.5	14.8	226	319	16
